Explosion-Proof Patrol Device is a specialized equipment that integrates explosion-proof technology with intelligent patrol functions. It is widely used in high-risk industries such as petrochemicals, coal mines, gas, and power. The device ensures the safety of patrol personnel in hazardous environments while improving the efficiency and accuracy of patrol operations. It features explosion-proof, waterproof, dustproof, and shock-resistant characteristics, enabling stable operation in harsh conditions. Can read NFC checkpoints very easily.
The OGP Patrol System allows security personnel to upload incident reports to the power management center when they discover incidents such as equipment damage, equipment loss, and equipment aging.
Ensure that incidents are discovered and resolved in a timely manner, avoiding greater potential safety hazards, and ensuring the stability and safety of power supply.
The patrol system can be used for safety inspections, such as checking the safety hazards such as cable wells, substation rooms, surrounding environment of high-voltage equipment, fire and leakage, etc., to ensure the safe and stable operation of power facilities.
Basic Specifications
- Model : F5 Explosion-Proof Patrol Device
- Type : 4G smart terminal, explosion-proof terminal, patrol terminal
- Main Screen Size : 2.4 inches
- Screen Type : Capacitive touch screen
- Screen Resolution : 240×320 pixels
- Design : 4G smart patrol terminal
- SIM Card Type : Single Micro SIM card
- Network Mode : GSM, CDMA, WCDMA, EVDO, TD-SCDMA, TDD/FDD-LTE
- Data Services : LTE CAT4, HSPA, TD-SCDMA, 1xEV-DO, EDGE, GPRS
- Supported Bands :
- GSM: 850/900/1800/1900 MHz
- LTE-FDD: B1/B3/B4/B5/B7/B8/B20/B28AB
- LTE-TDD: B38/B39/B40/B41
- WCDMA: 850/900/1900/2100 MHz
- TD-SCDMA: A/F (B34/B39)
- EVDO: BC0
- CDMA: 1X
- Theoretical Speed :
- LTE: CAT4 (150Mbps downlink, 50Mbps uplink)
- WCDMA: Category 24 HSDPA, Category 7 HSUPA
- TD-SCDMA: Category 14 (downlink), Category 6 (uplink)
- GSM: Class 12 GPRS, Edge
- Operating System : Android 8.1
- Main Control Platform : MTK6739, Quad-core 1.5GHz
- Storage : 8GB ROM + 1GB RAM, expandable up to 128GB
- Battery Capacity : 3.8V Lithium Polymer 4100mAh (3100mAh for explosion-proof version)
- Explosion-Proof Rating : Ex ib IIC T4 Gb/Ex ibD 21 T130℃
- Dimensions : 110mm (L) × 57mm (W) × 28mm (H)
- Weight : 205g (excluding clip)
